Multi Extension Air
Item No.: 100116
€520.01
excl. VAT
The Loxone Multi Extension Air provides 8 outputs with potential-free bistable relays, 12 digital inputs, a 1-wire interface and 4 PWM outputs.
Features:
- Can be placed anywhere, making it the most versatile extension for retrofitting projects
- 12 digital inputs:
- 0 - 28 VDC
- Can be used as a frequency counter (max 200Hz)
- Outputs:
- 8x digital: (relay), bistable, potential-free
- 4x PWM: 2.1A per channel (12-28VDC)
- 1-Wire interface:
- max. 20 sensors, (max. 50mA)
Technical details:
Power Supply:
18 ... 28VDC
Product dimensions:
158x88x59mm / 6.22x3.46x2.32” (LxWxH)
