Nano 2 Relay Tree Zoom
Nano 2 Relay Tree
Item no.: 100395

From blinds, gates, circulation pumps, an electric door lock or the bathroom extractor fan; the Nano 2 Relay Tree provides flexibility so you don’t have to wire anything that you need to switch back to the panel. When controlling blinds you will additionally benefit from the built-in end stop detection.

  • 2 volt-free 5A relays
  • Suitable for shading, lighting, fans and much more.
  • Fully automatic end stop detection
  • Designed for use in a Real Smart Home
  • Intuitive commissioning thanks to Loxone Tree technology
  • Compact design - 42x39x20.5mm
96.00
Including 20% VAT, excluding shipping
In stock. Delivery within 3-5 working days.

For switched circuits

In any installation, you’ll have something that needs switching; blinds, curtains, bathroom fans, circulation pumps, garage doors, gates, door locks, etc…

Meet the Nano 2 Relay Tree – the counterpart to the Nano DI Tree which you are already familiar with.

The 2 volt-free 5A relays allow you to switch loads around your installation – conveniently controlled with Tree – avoiding the need to run your switch circuit back to your main distribution board.

For switched circuits

In any installation, you’ll have something that needs switching; blinds, curtains, bathroom fans, circulation pumps, garage doors, gates, door locks, etc…

Meet the Nano 2 Relay Tree – the counterpart to the Nano DI Tree which you are already familiar with.

The 2 volt-free 5A relays allow you to switch loads around your installation; conveniently controlled with Tree – avoiding the need to run your switch circuit back to your main distribution board.

Two relays for local switching

From switched lighting circuits, a gate motor, heating pump, motorised door lock or bathroom extractor fan; the Nano 2 Relay Tree provides flexibility so you don’t have to wire anything that you need to switch back to the panel.  This minimises cable required at first-fix, reduces the overall installation time, and complexity.

The two relays are volt-free 5A relays that can handle up to 250VAC. Please note that LED lighting can present very high inrush currents.

For automatic shading
– with end stop detection

The Nano 2 Relay Tree automatically detects the end position of blinds. This not only saves a considerable amount of time during installation but also saves tiresome recalibration of the travel times. Due to the fully automatic end stop detection, the current position of the shading is displayed immediately and accurately within the app.

For automatic shading
– with end stop detection

The Nano 2 Relay Tree automatically detects the end position of the blinds. This not only saves a considerable amount of time during installation but also saves tiresome recalibration of the travel times. Due to the fully automatic end stop detection, the current position of the shading is displayed immediately and accurately within the app.

Designed for a Real Smart Home

This versatile new product has been developed to seamlessly work in a Loxone Smart Home. As part of this seamless integration, Loxone Auto Config can help to realise the following functionality from the onset:

Switch Standard

Frost Protection

Storm Protection

Centralised Control

Automated Shading

Loxone Tree: smart homes in record time

The Nano 2 Relay Tree and all other Tree products intuitively work perfectly together – offering unparalleled functional assurance. Thanks to the versatility of Loxone Tree, combined with the know-how of a Loxone Partner, installation can be done in record time.

Contents

1x Nano 2 Relay Tree
1x Quick Start Guide
